FrSky L9R Long Range Receiver for FrSky Taranis X9D
6 available
Details
Shipping: Australia: $9.00 (more destinations)
Condition: Brand new
*The store has not been updated recently. You may want to contact the merchant to confirm the availability of the product.
FrSky L9R Long Range Receiver for FrSky Taranis X9D
Package includes:
1 FrSky L9R Receiver
Brief Description;
Dimensions: 46.25x26.6x14.2mm (L x W x H)
Weight: 19gm
Antenna: PCB Antenna
Number of Channels: 1-9ch from conventional channel outputs, 1-12ch from SBUS port
RSSI output: Analog RSSI output (0-3.3V)
Operating Voltage Range: 4.0-10V
Operating Current: 100mA@5V
Operating Range: approx. 2 times that of X-series receivers
Compatibility:
FrSky X-series Module (XJT) etc in LR12 mode (Switch 1 is OFF, Switch 2 is ON)
FrSky Taranis X9D etc. in LR12 mode
Tech Note:
L9R receiver will not work with FrSky V8, D8, and D16 Mode.
IMPORTANT:
L9R has a bind protocol that differs from the X series - PLUS fail-safe is set to last signal by default, so the user must ensure to set the fail-safe to work as preferred. Fail-safe cannot be set from the TX, so the manual should be consulted for the relevant information
